Ceiling Lift Track System

A purple logo that says nca we move better.VANCARE ceiling track systems help ensure the successful operation of your ceiling lift operation. We offer a large selection of track styles, track curves, and other components. You can trust your VANCARE representative to help you develop a track system that fits your unique needs.

A close up of the side rail on a white plastic fence.Straight Track

VANCARE straight aluminum track can be used in linear rail applications or as the support rails for an X-Y gantry system. Available in 6’4†(1.93 m), 8’2†(2.5 m), 10’2†(3.07 m), and 16’5†(5.0 m) lengths.

A close up of the side rail on a white plastic fence.Super Track

VANCARE offers the thicker profile of Super Track, which allows for extended spans between supports, making it ideal as the traverse boom for X-Y gantry systems and for Wall Mounting applications. Available in 10′ (3.0 m) and 12.5″ (3.73 m) lengths.

A close up of the side of a white plastic fence.Track Plus

VANCARE’s Track Plus is most commonly used to accommodate longer, unsuspended spans. Available in 16.5’ (5.0 m) and 19’8†(6.0 m) lengths. Ideal for traversing booms in two-bed suites, PT rooms and anywhere long unsuspended spans are needed.

A white plastic straw is hanging on the wall.Curve Track 45 Degree

Curved tracks are used to change the direction of tracks in a single-track system. The 45 Degree Curve can be used with other straight or curved tracks. Available in “inside” and “outside” designs to allow for the finished side of the track bracket to remain consistent throughout the installation.

A white tube of plastic is bent to the side.Curve Track 90 Degree

Curved tracks are used to change the direction of tracks in a single track system. The 90 Degree Curve can be used with other straight or curved tracks. Available in “inside” and “outside” designs to allow for the finished side of the track bracket to remain consistent throughout the installation.

Quick Curve 90 Degree

This curve is currently available for the P-Series and C-Series Manual Ceiling Lifts. The Quick Curve is a 90-degree curve with a turning radius of 8″ potentially avoiding the requirement for more costly installation options. Mounted only to the adjacent sections of straight track, the Quick Curve offers a more cost effective installation.

A white ceiling mounted air conditioner in the corner of a room.Wall Mount System

The Wall Mount System is used as an alternative to ceiling mounting. The system comes complete with all hardware and can be      attached directly into drywall provided that it is at least 3/8″ thick. Quickly installed, the Wall Mount System offers the same stability as      ceiling installations. It can be used for pre-existing as well as new construction.

A white ceiling mounted air conditioner in the corner of a room.Wall Mount 6″ Bracket

Sold separately, the Wall Mount 6″ bracket is used with the Heavy Duty Wall Bracket to attach the track.



A white plastic object sitting on top of a floor.Wall Mount Bracket

The Wall Bracket allows for track to be installed directly into the wall where ceiling mounted applications are not practical.



A round mirror with a white frame and a silver strip.Multi-Port Turntable 16 Port

The Multi-Port Turntable provides the end-user with ultimate flexibility in lift and transfer situations that demand a wide range of locations. The turntable provides 15 different ceiling track take-off points at 22-degree intervals. The turntable is easily rotated with the use of a simple pull-cord mechanism.

Power Multi-Port Turntable 14 Port

The Power Multi-Port Turntable offers the end-user ultimate flexibility in situations that require access to a number of transfer locations. The turntable provides 14 take-off points.

A white plastic device with a handle on it.Quick-Fit Turntable

The Quick-Fit turntable allows for directional change at 90-degree intervals. The turntable is rotated using a simple pull-cord mechanism.
